Key Features
6th Gen Intel® Core™ i7/i5/i3 Processors with QM170 Chipset
Single-side I/O access and two hot-swappable SATA drive bays for easy maintenance
1x DVI-I, 2x DisplayPort, 4x USB 2.0, 4x USB 3.0, 4x GbE, 6x COM, and 8x Isolated DI/O
Versatile storage options with 2x 2.5" SATA III (6.0 Gb/s) ports, 1x M.2 2280 slot, and 1x CFast socket
Flexible expansion with 2x mPCIe slots and 2x USIM slots
**Rugged fanless design supporting a wide operating temperature range of -20°C to +60°C (70°C)* (*Industrial-grade SSDs required)**
Integrated Avalue SEMA® 3.0 management solution
Use Cases
Ship Intelligent Control System Solution
Smart Building Automation Applications
Intelligent Transportation: ETC Lane Controller
Stadium Operations Dispatch Wireless Communication Solution
Dimensional Measuring Instrument Applications
